Model Name

Indoor

HSU-19K(INV)(H&C)

Outdoor

HeatCool(INV)(Pro)

Category

Inverter

Series

Inverter

Capacity and Parameters

Type

Inverter

Ton Range (TR)

1.6 Ton

Capacity(BTU)

19000

Rated Cooling Capacity (W)

5570

Rated Heating Capacity (W)

19000

Rated Power Input Cooling (W)

1720

Rated Power Input Heating (W)

1630

Max. Power input Cooling (W)

2000

Max. Power input Heating (W)

2000

Energy Effeciency Ratio (EER)

2.93

Seasonal Energy Efficiency Ratio (SEER):

3.80

Coefficient of Performance (COP)

N/A

Rated Running Current (A) Cooling

7.5

Rated Running Current (A) Heating

7.2

Max.Running Current (A) Cooling

8.6

Max.Running Current (A) Heating

8.9

Power supply (Ph,V,Hz)

1/230/50HZ

Air Circulation (m3/h)

1100

Moisture Removal (10-3m3/h)

N/A

Refrigerant Standard (Kg)

.970

Refrigerant Type

R32

Refrigerant Pipe Liquid Side Diameter (mm)

6

Refrigerant Pipe Gas Side Diameter (mm)

12

Compressor Type

Rotary

Evaporator/Condenser

100% 7mm Grooved Copper

Heat Exchangers

Golden Fin

Indoor

Indoor Net dimension (mm) W/D/H

975*220*318

Indoor Package dimension (mm) W/D/H

1050*397*301

Indoor Net weight (kg)

13

Indoor Gross weight (kg)

14.5

Indoor Sound power level [dB(A)] Hi/Mid/Lo

47/43/39

Outdoor

Outdoor Net dimension (mm) W/D/H

820*306*642

Outdoor Package dimension (mm) W/D/H

942*392*693

Outdoor Net weight (kg)

35

Outdoor Gross weight (kg)

38

Outdoor Sound power level [dB(A)] Hi/Mid/Lo/So

55

Air Flow Direction

Up & Down

Auto

Left & Right

Manual

User Functions

Heating Cooling

YES

Wifi:

Yes

Voice Control

Yes

Energy Savings:

Yes (Up to 65%)

Self Clean:

Yes

ECO Mode:

Yes

Turbo Function:

Yes

Auto Restart Function:

Yes

Sleep Mode:

Yes

Low Noise:

Yes

Timer:

Yes

Quick & Easy Installation:

Yes

Child Lock:

Yes

Product Warranty
