Model Name

Indoor

HSU-18ReviveCool(INV)(Pro)(X6)

Outdoor

HSU-18K(INV)(Pro)(X6)

Category

Inverter

Color

White

Series

Inverter

Capacity and Parameters

Type

Inverter

Ton Range (TR)

1.5 Ton

Capacity(BTU)

18000

Rated Cooling Capacity (W)

5000

Rated Heating Capacity (W)

N/A

Rated Power Input Cooling (W)

1310

Rated Power Input Heating (W)

N/A

Max. Power input Cooling (W)

1900

Max. Power input Heating (W)

N/A

Seasonal Energy Efficiency Ratio (SEER):

3.80

Coefficient of Performance (COP)

N/A

Rated Running Current (A) Cooling

7.0

Rated Running Current (A) Heating

N/A

Max.Running Current (A) Cooling

8.5

Max.Running Current (A) Heating

N/A

Power supply (Ph,V,Hz)

1/230/50HZ

Air Circulation (m3/h)

1100

Moisture Removal (10-3m3/h)

N/A

Refrigerant Type

R32

Refrigerant Standard (Kg)

0.800

Refrigerant Pipe Liquid Side Diameter (mm)

6

Refrigerant Pipe Gas Side Diameter (mm)

12

Compressor Type

Rotary

Evaporator/Condenser

100% 7mm Grooved Copper

Heat Exchangers

Golden Fin

Indoor

Indoor Net dimension (mm) W/D/H

975*220*318

Indoor Package dimension (mm) W/D/H

1050*397*301

Indoor Net weight (kg)

12.5

Indoor Gross weight (kg)

15.0

Indoor Sound power level [dB(A)] Hi/Mid/Lo

47/43/40

Outdoor

Outdoor Net dimension (mm) W/D/H

800*280*553

Outdoor Package dimension (mm) W/D/H

908*405*627

Outdoor Net weight (kg)

24.5

Outdoor Gross weight (kg)

29.5

Outdoor Sound power level [dB(A)] Hi/Mid/Lo/So

55

Air Flow Direction

Up & Down

Auto

Left & Right

Auto

User Functions

Self Clean

Yes

Energy Savings

Yes (Up to 65%)

ECO Mode

Yes

UVC Pro Technology

No

Wifi

No

Dry Mode

Yes

Turbo Function

Yes

Auto Restart Function

Yes

Sleep Mode

Yes

Low Noise:

Yes

Timer

Yes

Quick & Easy Installation

Yes

Child Lock:

Yes
