Model Information:

• Indoor Unit: HSU-19UltimateCool (INV) (Pro) (X6) (T3)
• Outdoor Unit: HSU-19K (INV) (Pro) (X6) (T3)

Category:

• Type: Premium Inverter
• Series: Inverter

Capacity & Performance:

• Capacity: 19000 BTU
• Ton Range: 19000 BTU
• Cooling Capacity:
  • T1: 19000 BTU/h
  • T3: 16000 BTU/h
• Heating Capacity: 19000 BTU/h
• Cooling Capacity (W):
  • T1: 5570
  • T3: 4690
• Rated Power Input (W):
  • Cooling: T1: 1465 / T3: 1680
  • Heating: 1520
• Max Power Input (W):
  • Cooling: 1990
  • Heating: 2330
• SEER: 3.80
• EER: 2.93
• Rated Running Current (A):
  • Cooling: T1: 6.4 / T3: 7.3
  • Heating: 6.6
• Max Running Current (A):
  • Cooling: 8.8
  • Heating: 10.2
• Power Supply: 1 / 230V / 50Hz
• Air Circulation: 1100 m³/h

Refrigerant & Piping:

• Refrigerant Type: R32
• Refrigerant Charge: 1.200 Kg
• Liquid Side Diameter: 6 mm
• Gas Side Diameter: 12 mm

Indoor Unit:

• Net Dimension (mm): 975 × 220 × 318
• Package Dimension (mm): 1050 × 397 × 301
• Net Weight: 13.0 Kg
• Gross Weight: 14.5 Kg
• Sound Level (Hi/Mid/Lo): 47 / 43 / 39 dB(A)

Outdoor Unit:

• Net Dimension (mm): 820 × 306 × 642
• Package Dimension (mm): 940 × 390 × 697
• Net Weight: 38.0 Kg
• Gross Weight: 41.0 Kg
• Sound Level: 58 dB(A)

Features & Operation:

• HaiSmart App Control: Yes
• Voice Control (3rd Party): Yes
• UVC Pro Sterilization: Yes
• Hot & Cool Mode: Yes
• iFeel Technology: Yes
• ECO Mode: Yes
• AI Climate Control: Yes
• AI ECO Mode: Yes
• Sleep Mode: Yes
• Fan Mode: Yes
• Timer: Yes
• Sleep Light On/Off: Yes
• Automatic Error Detection: Yes
• Child Lock: Yes
• Auto Restart: Yes

Warranty:

• Compressor: 12 Years
• Spare Parts & Components: 5 Years
• Free Home Service: 5 Years
