Basic Information

• Brand: Walton

• Model: WCG-3J0-RXLX-XX

• Type: Frost / Direct Cool Freezer

• Gross Volume: 300 Liters

• Net Volume: 300 Liters

• Refrigerant: R600a

• Note: Color depends on stock availability

Performance

• Climatic Type: N ~ ST

• Rated Voltage & Frequency: 220–240V / 50Hz

• Cooling Effect: Freezer Cabinet less than -18°C

• Temperature Control: Mechanical

• Defrost System: Manual

• Caster: No

Compressor & Cooling System

• Compressor Input Power: Multiple variants (154W / 235W / 147W / 118W depending on version)

• Compressor Type: RSCR / CSIR (variant-based)

• Wide Voltage Range: 15V–260V / 145V–260V (variant-based)

• Refrigerant Variants: R134a / R600a (model dependent)

• Condenser: Steel

• Capillary: Copper

• Thermostat: RoHS Certified

General Features

• Door Type: Foaming Door

• Handle: Yes (Grip Type)

• Lock: No

• Foam Blowing Agent: Cyclopentene (100% CFC & HCFC Free Green Technology)

• Voltage Stabilizer Recommendation: Model dependent

Freezer Compartment

• Exterior Material: Painted Steel (PCM)

• Interior Material: Embossed Aluminium Sheet

• Basket: Wire / 1

• Shelf: Wire / 1

• Drawer: No

• Interior Lamp: Yes

Dimensions

Net Dimension

• Width: 1210 mm

• Depth: 680 mm

• Height: 860 mm

Packing Dimension

• Width: 1280 mm

• Depth: 725 mm

• Height: 890 mm

Weight

• Net Weight: 49 ± 2 Kg

• Gross Weight: 56 ± 2 Kg

Loading Capacity

• 20ft: 26 Units

• 40ft: 54 Units

• 40HQ: 81 Units

Special Features

• Wide Climate Design

• Magical Nano-Silver Technology in Plastic

Warranty (Residential Use)

• Replacement Guarantee: 1 Year (conditions apply)

• Compressor: 12 Years

• Door: 3 Years

• Spare Parts: 4 Years

• After Sales Service: 5 Years

Warranty (Commercial Use)

• Compressor: 4 Years

• Door: 1 Year

• Spare Parts: 2 Years

• After Sales Service: 2 Years

Warranty Terms

• Warranty does not cover accidental, electrical, natural damage or improper installation

• Unauthorized modification voids warranty

• Serial number tampering voids warranty

• Only manufacturing defects are covered after company verification
